Z Purlin Forming Machine

Technical parameter:
Main power: 18.5KW
Forming station: 16 stations and 5 rolls are for leveling
Z Purlin Roll Forming Machine Diameter of shaft: ф80mm
Cutting system: hydraulic
Tolerance: 3m±1.5mm
Speed: 12-15m/min (Not including cutting)
Material of the rollers: GCr15, hard chromed 58--62degrees
Material of shaft: GCr15 steel, quenching HRC58○-60○
Material of blade and punching mould: Cr12, quenched 58-62
Z Purlin Roll Forming Machine Transducer: Panasonic made in Japan
Hydraulic main motor: 7.5kw
Cutting pressure: Max.20Mpa
Control system: PLC, Panasonic
Z Purlin Roll Forming Machine Rolled thickness: 1.5mm--3mm
Size of machine: approx 13.2m×1.4m×1.2m
Z Purlin Roll Forming Machine Way of drive: chain drive
Electrical requirements: 380V, 50Hz, 3Ph or according to the customer's local standard

Model:

MODEL H B C T
Z145 145 60 60 20 1.5-3.0
Z180 180 67 61 20 1.5-3.0
Z200 200 67 61 20 1.5-3.0
Z230 230 72 77 20 1.5-3.0
Z250 250 78 72 20 1.5-3.0
Z300 300 78 72 20 1.5-3.0
